Max speed:120m/min
Automatic cylinder lifting when machine stop to avoid the material broken
Individual unwinder & rewinder for jumbo roll
Flexo Press Advantage
1.Control method: PLC control
2.Ceramic anilox roller: with ceramic anilox roller, line number 50PLI ~ 800PLI.
3.Ink: Adopted automatic circulation system, and a single small motor is used for inking.
4.Speed regulation: Adopted frequency conversion speed regulation, small fluctuations in operation
5.Unwind EPC: using high-end automatic photoelectric correction control system
6.Unwinding and rewinding methods: using magnetic powder automatic tension control
7.Inking method: single-side doctor blade inking.
8.Lifting and falling plate: hydraulic automatic landing plate
9.Steel roller: It is processed by special steel and processed by special technology, and it is plated with 8-wire thick hard chrome protective layer, with a runout below 0.03mm
10.Traction guide roller: adopted semi-sealed small bearings made in Japan for static balance and dynamic horizontal treatment, hard oxidation treatment, low resistance and small runout
11.Drying device: It is equipped with three sets of ventilation and blower heating devices, in which the heating is controlled by a central constant temperature control system and grouped control
12.Body: thicker wall plate and base, making the machine more stable.
Technical parameter:
|
Machine model
|
LYT4-800
|
LYT4-1000
|
LYT4-1200
|
LYT4-1300
|
|
Max. Printing material width
|
800mm
|
1000mm
|
1200mm
|
1300mm
|
|
Max. Printing width
|
760mm
|
960mm
|
1160mm
|
1260mm
|
|
Max. Unwinding diameter
|
1300mm
|
|
Max. Rewinding diameter
|
1300mm
|
|
Printing length range
|
228-1000mm
|
|
Printing speed
|
5-100m∕min
|
|
Register precision
|
≤±0.15mm
|
|
Printing color
|
As required
|
