PLC Control And Touch Screen
Automatic cylinder lifting when machine stop to avoid the material broken
High Printing Precision
Most Competitive Price
Advantages of PP, HDPE and LDPE Materials Printing Machine
This Self-laminating labels printing machine has the characteristics of wide printing range, no pollution of ink, high economic benefit and fast printing speed.
1. This foil and embossed labels printing machine's main motor adopts imported electric frequency speed regulation.
2. Automatic tension control of this PET packaging materials printing machine is used for unwinding.
3. Ultrasonic rectification is used on this cardboard and corrugated board materials printing machine for web guide.
4. Part of the print label machine sticker is using ceramic anilox rollers, has the characteristics of long service life, wear resistance, corrosion resistance.
5. Printing unit of this tea bag tags flexo printing machine adopts 360 degree circumscribed alignment adjustment. The printing units can be individually joined or loosened so that other printing units continue to print.
6. Each printing unit of label stock printing machine is equipped with infrared drying device.
7. This self-adhesive labels printing machine is with die cutting function.
8. Automatic metering.
9. Parking roller can be automatically disengaged, and low speed dynamic convey to prevent dry ink.
10. Rolls for paper, printing, automatic infrared drying, die cutting and rewinding finished once.
Technical Parameters of Double-sided Labels Printing Machine:
|
1
|
Machine model
|
RY1-320
|
|
2
|
Printing speed
|
65m/min
|
|
3
|
Printing color
|
1
|
|
4
|
Paper max width
|
320mm
|
|
5
|
Max printing width
|
310mm
|
|
6
|
Max unwinding diameter
|
600mm
|
|
7
|
Max rewinding diameter
|
600mm
|
|
8
|
Printing perimeter
|
175-350mm
|
|
9
|
Precision
|
±0.1mm
|
|
10
|
Main motor powder
|
1.5kw
|
|
11
|
Total powder
|
4kw
|
|
12
|
Machine size
|
1900×1100×1500mm
|
|
13
|
Machine weight
|
about 1000kg
|
