HC-C650/1300/1600B Surface Coil Slitting Machine

Name: HC-C650/1300/1600B Surface Coil Slitting Machine
Brand: RUIAN LOYAL MACHINERY CO., LTD.

This PI film slitting machine is suitable for the slitting of metallic material: aluminum foil, copper foil, PET CCL, PPE, Personal protective gowns, medical gowns, BOPP, PET, CPP, PE, PVC, film, paper, PSP DPP Paper,etc.

Tel:+86 18367750188

Email:ly@lyslitter.com

To get an instant quote Now

Application Technical parameter FAQ Case Share

Application

Use of HC-C650/1300/1600B Surface Coil Slitting Machine

This machine is suitable for the slitting of straw paper, aluminum foil, copper semiconductor, PET CCL, PPE, Personal protective gowns，medical gowns，BOPP, PET, CPP, PE, PVC, film, paper, DPP Paper,PSP Paper etc.

Characteristic of HC-C650/1300/1600B Surface Coil Slitting Machine

-Servo motor control, automatic taper tension, the center surface coiling method;
-Frequency control, to maintain smooth operation in the acceleration;
-Automatic meter, alarm and other functions;
-Rewinding using A, B inflatable shaft structure, back-style rewinding, loading and unloading easy operation;
-Unwinding using optical edge correction method;
-round knife (film using flat knife structure) slitting waste automatic discharge device;
-pneumatic automatic shaft / hydraulic automatic shaft-free structure (customers choose their own configuration).

Technical parameter

1	Machine model	HC-C650B	HC-C1300B	HC-C1600B
2	Unwinding width	650mm	1300mm	1600mm
3	Slitting thickness	12g/m^2~300g/m^2	12g/m^2~300g/m^2	12g/m^2~300g/m^2
4	Standard slitting width	5~650mm	5~1300mm	5~1600mm
5	Slitting speed	300m/min	300m/min	300m/min
6	Unwinding roll diameter	Φ600mm	Φ1000mm	Φ1000mm
7	Rewinding roll diameter	Φ600mm	Φ600mm	Φ600mm
8	Main motor power	3kw	7.5 kw	7.5 kw
9	Rewinding motor power	2×3kw	2×7.5kw	2×7.5kw
10	Machine weight	2500kg	3000kg	3500kg
11	Installation dimension	250018501800mm	315025001800mm	315028001800mm

FAQ

1:Surface coil slitting how to control rewinding tension?
The rewinding shaft is pressed on the roller for slip rewinding, and the pressure can be controlled by a precision pressure regulating valve

2:What should I pay attention to when cutting 5mm on the surface coil slitter?
The surface of the rolled plastic core should be flat, without wear and tear, and the height should be consistent.

3:What is the minimum slitting width for 1600mm surface coiling?
20mm.

4:What materials can be slitted by your coil slitting machine?
Professionally for flexible film, lithium battery film in new energy industry, and copper foil, aluminum foil, paper and etc.

5:How about the machine installation and operation when. Machine delivery to our factory?
Machine as usual is integrated and we do not dismantle before delivery.
So just connect the power cable and air pipe is ok.
For the operation, we take detailed instruction video for all customers before delivery to guide you how to operate, and provide the detailed operation manual.
Also, we provide service: our engineer and technician open live training until you learned it and run it well.

6: How about the guarantee?
Ø 12 months guarantee, life-long time technic maintenance and support. 24 hours feedback when receive the client writing proposal.
Ø Any part damage caused by non-human factors within the warranty period can be replaced for free, excluding machine consumable parts. Maintenance of part damage caused by violation operation or mis-operation of operators will be charged with costs of parts.
Ø The price of spare parts exceeding the warranty period shall be the lowest ex-factory price of the seller.
Ø For extra accessories beyond the standard configuration of contractual machine, the price shall be the lowest ex-factory price of the seller.

Any time you have question about slitter, we are always here to provide service.

Case Share

Meeting Rotas for the first time was at LABELEXPO exhibition in Shanghai. He came and stopped by our stand, with the classic and elegant smile. After short talk, we knew he is from Thailand and runs a very reputable company of release film and other materials. Also, he has built a new plant and plans to purchase a slitter to convert the flexible pet material. The inquiry for the slitter is to slit very narrow film width 5mm and also want to slit back side of the material.

Thanks for Rotas’s detailed requirement, Raloyal, in the spot recommended HC-C series slitter, in the meantime, with the tailed solution for back slitting technology. We sent the solution files to Rotas after the exhibition. This solution can perfectly meet Rotas ‘s demand,andprice is good.

After 2 months, the end of 2019, we have concluded the deal smoothly like water flowing to a channel formed.

After shipment, due to the epidemic, wecould not go to Thailand, so the training was online (by wechat group video) with our service engineer. They learned the machine operation very quickly, and ran very well only within 1 day. Thanks for our service engineer ‘s profession and patience, also the operator ‘s earnestness there.

The machine runs very well in our customer’s factory, and he took a video for us below.

And 2 days ago, we made the after-sale service follow-up. This is their feedback.
