HC-Z High Speed Slitting Machine

Name: HC-Z High Speed Slitting Machine
Brand: RUIAN LOYAL MACHINERY CO., LTD.

This type of slitter rewinder is the most ideal machine for jumbo roll slitting and rewinding. Max rewinding diameter can reach to 1000mm.

Tel:+86 18367750188

Email:ly@lyslitter.com

To get an instant quote Now

Feature Application Our Difference Video FAQ Case Share

Feature

1000mm unwinding diameter, Jumbo roll automatic unloading.It is ideal equipment for paper, film high precision demand material slitting. Separated unwinding section, 3 sets 11kw servo motor control.

Application

This machine is suitable for slitting and rewinding jumbo roll with high precision, such as sticker paper, kraft paper, double sides silicone coated paper, white cardboard, laminating paper, film, etc.
· Raw paper, release paper, paper board
· Adhesive paper
· Protective film
· PET, PVC, etc. film
· Release Liners (Paper/ Film) and Label Stocks
· Release Paper Liners
· Release Film Liners
· Self Adhesive Paper Label Stocks (Cromo Art, Maplitho, Mirror Coat, Flourocent paper,Thermal Transfer, Aluminium foil paper( golden and silverl )
· pvc film label stocks
· vinyl film label stocks
· polyester film label stocks
· Self Adhesive Film Label Stocks (Polyster Film (metalized/Clear)
· PVC Film(Color/ Transparent)
· Vinyls(Colour/Transparent) and Specialty Adhesive Tapes / Label stocks

Our Difference

*PLC control, automatic tension control.
*3 servo motors drive(4kw+11kw+11kw), central surface rewinding
*Ultrasonic web guide
*Splicing table for friendly material connecting.
*Frequency inverter timing for main machine, keeping speedup and stable operation.
*It has the functions of automatic metering, automatic alarm, automatic stop by setting length you need.
*Rewinding adopted the A, B air expansion shaft structure.
*Double idler type lay on roller for rewinding stably.
*Unloading frame automatic lifting up and down by chain, unloading safe and conveniently. (from machine to the floor.)
*Shaft less automatic loading with hydraulic.
*Circular knife automatic slitting device for waste edge scraping (Blower exhaust waste).

Technical parameter:

1	Machine model	HC-Z1300/1600
2	Slitting effective width	50-1200/1600mm
3	Slitting speed	300m/min
4	Unwinding roll diameter	Φ1200mm
5	Rewinding roll diameter	2*Φ1000mm
6	Main servo motor	4kw
7	Rewinding servo motor	11kw*2
8	Suitable power supply	380V, 3 three-phas, 50hz
